Vom ersten Schaltplan bis zur geprüften Serie – aus einem Haus. Entwicklung und Fertigung sitzen hier zwei Türen auseinander, und genau das merkt man einem Zeitplan an.
From the first schematic to tested series production – under one roof. Development and manufacturing sit two doors apart here, and a project schedule shows it.
Der Weg zu Ihrer Hardware
The way to your hardware
Drei Abschnitte, die ineinandergreifen. Dass sie im selben Haus stattfinden, ist kein Werbesatz: Wer den Layouter fragen kann, ob sich etwas so fertigen lässt, spart die Schleife, in der sonst zwei Firmen aneinander vorbeireden.
Three stages that interlock. That they happen in the same building is not a slogan: being able to ask the layout engineer whether something can actually be built saves the loop in which two companies otherwise talk past each other.
Architektur
Architecture
Anforderungen klären, Bauteile auswählen, das technische Konzept aufstellen. Hier fällt die Entscheidung, die später am teuersten zu korrigieren wäre.
Clarify requirements, select components, set up the technical concept. This is where the decision is made that would cost the most to reverse later.
Iteration
Iteration
Schaltplan, Layout und Prototypen aus der eigenen Fertigung. Eine neue Leiterplatte liegt in Tagen auf dem Tisch, nicht in Wochen.
Schematic, layout and prototypes from our own production. A new board is on the table within days rather than weeks.
Serie
Series
Serienfertigung nach IPC-A-610D, RoHS-konform, einschließlich der Testabläufe. Was in der Entwicklung geprüft wurde, wird auch in der Serie geprüft.
Series production to IPC-A-610D, RoHS compliant, test procedures included. Whatever was verified during development is verified in production too.
Hardware, die sich fertigen lässt
Hardware that can actually be built
Wir zeichnen Schaltpläne und Layouts für elektronische Baugruppen aller Art – unter den Normen, die für das jeweilige Produkt gelten, und mit Blick auf die EMV, bevor sie im Prüflabor zum Problem wird.
We draw schematics and layouts for electronic assemblies of every kind – to the standards that apply to the product in question, and with an eye on EMC before it becomes a problem in the test lab.
- Konzeption und Bauteilauswahl
- concept and component selection
- Schaltplan und Layout nach geltenden Normen
- schematic and layout to the applicable standards
- Aufbau und Expressfertigung von Prototypen
- building and express production of prototypes
- Begleitung bis zur Zertifizierung
- support through to certification
- Übergang in die Serienfertigung
- transition into series production
Software dicht an der Hardware
Software close to the hardware
Die Schaltung allein tut nichts. Wir schreiben die Firmware dazu – optimiertes C und C++, Funkstacks für UWB und Bluetooth, dazu die Anbindung an Anwendungen auf iOS und Android.
A circuit on its own does nothing. We write the firmware to go with it – optimised C and C++, radio stacks for UWB and Bluetooth, plus the link to applications on iOS and Android.
- Architektur und Konzeption der Software
- software architecture and concept
- µController: STM32, nRF52, PIC, AVR, ARM Cortex, PSoC
- microcontrollers: STM32, nRF52, PIC, AVR, ARM Cortex, PSoC
- Linux-Treiber und Board Support Packages
- Linux drivers and board support packages
- vollständige Anwendungen auf Wunsch
- complete applications on request
- Versionsverwaltung mit Git, Ticketsystem im Projekt
- version control with Git, issue tracking in the project
Der Maschinenpark
The machine park
Wir bestücken maskenlos. Die Druckdaten entstehen aus den Gerber-Daten, und die Leiterplatte wird direkt bedruckt – deshalb ist eine Expressfertigung in 24 Stunden überhaupt möglich. Eine Schablone müsste erst gefertigt werden.
We assemble without stencils. The print data come from the Gerber files and go straight onto the board – which is what makes 24-hour express production possible at all. A stencil would have to be made first.
- elektrische Rüstkontrolle für Widerstände, Kondensatoren, Dioden und Transistoren
- electrical setup verification for resistors, capacitors, diodes and transistors
- Auf- und Abrüsten per 2D-Barcode nach Vorgabe der Warenwirtschaft
- setup and teardown by 2D barcode, directed by the ERP system
- verbrauchtes Material verbucht sich chargen- und baugruppengenau von selbst
- material consumed is booked automatically, by batch and by assembly
- über 40.000 Bauteile je Stunde Bestückleistung
- more than 40,000 components per hour of placement capacity
Lohnfertigung
Contract manufacturing
Wir fertigen Ihre Baugruppen – ob Sie die Bauelemente beistellen oder unsere Einkaufskonditionen nutzen wollen, entscheiden Sie. Auf Wunsch geht die Ware direkt und diskret an Ihre Kunden, ohne Umweg über Ihr Lager.
We build your assemblies – whether you supply the components or use our purchasing terms is up to you. On request the goods go directly and discreetly to your customers, without a detour through your warehouse.
- Expressbestückung in 24 Stunden möglich
- express assembly within 24 hours possible
- 100 Prozent Rückverfolgbarkeit, los- und chargengenau
- 100 per cent traceability, by lot and by batch
- SMT, THT und Mischbestückung
- SMT, THT and mixed assembly
- elektrischer Test, Montage, Gehäusebearbeitung
- electrical test, assembly, enclosure machining
- Fertigungsunterlagen und Leiterplattenbeschaffung auf Wunsch
- production documentation and board procurement on request
Lassen Sie uns Ihre Idee bauen
Let us build your idea
Sagen Sie uns, was das Gerät können soll und in welcher Stückzahl es entstehen wird. Auf eine Anfrage antworten wir innerhalb eines Arbeitstages – auch dann, wenn die Antwort lautet, dass jemand anderes besser passt.
Tell us what the device has to do and in what quantity it will be made. We answer an enquiry within one working day – including when the answer is that somebody else suits you better.
