The radino40 Stick RP-SMA is a USB stick used as a carrier board for all radino40 radio modules.
The radino40 modules are equipped with an nRF52840 microcontroller from Nordic Semiconductor. They provide optimal connection of the radio chips at the lowest sleep current.
Features:
- 3.3V voltage regulator
- USB-A connector with USB-UART bridge CP2102
- Programming and debugging via USB-UART
- 2 buttons
- 3 LEDs
- RP-SMA connector for an external antenna
- Bluetooth® antenna
- matching housing available
Delivery:
We provide extensive software examples with source code in our wiki.
Delivery includes an integrated bootloader.
An RP-SMA antenna is not part of the scope of delivery.
FiRa: With the radino40 DW3000 radio module the stick becomes a UWB node to FiRa, e.g. for positioning with a smartphone.
Links & Downloads:
| Weight | 8 g |
|---|---|
| Dimensions | 55 × 25 × 12 mm |
| Funkmodul | radino40 DW1000, radino40 DW1000 TCXO, radino40 DW3000, radino40 CC1101 433 MHz, radino40 CC1101 868 MHz |
| HS Code | 85423190 |
| Material | Leiterplatte, ohne Gehäuse |
| Colour | Blau |
| Spannungsversorgung | USB |
radino40 Stick RP-SMA
radino40 Stick RP-SMA is a USB stick used as a carrier board for all radino40 radio modules.
The radino40 modules are equipped with an nRF52840 microcontroller from Nordic Semiconductor. They provide optimal connection of the radio chips at the lowest sleep current.
excl. VAT plus shipping
Lieferzeit: ships immediately
Planning a larger quantity? Tell us how many and we will send you a quote.
Antenna, Ultra-Wideband (UWB), channel 5, male RP-SMA, +2.5 dBi at 6.5 GHz
Antenna, Ultra-Wideband (UWB), 3-8GHz, RP-SMA, +2.2 dBi at 4 GHz, +3.3 dBi at 6.5 GHz
